Lighting
Almost 11” of full-spectrum lighting around the needle with five adjustable brightness settings including off.

Needle threader
Easy to use, automatic needle threading system.

Bobbin winder
Independent bobbin winder system with adjustable winding speed.

Wireless
Wireless LAN capability for exchange of embroidery data with PE-Design 11, mobile apps and updates.

Thread tension
Automatic thread tension.

Thread cutter
Trims upper and lower threads automatically.

Presser foot
Automatic presser foot lift and extra high lift.

Thread sensors
Gives you a warning when your upper and lower threads are running low.

Teaching movies
Wide selection of built-in tutorial videos and MP4 playability.

Start/stop button
Ergonomic large start/stop button.

Environment
Save energy with the Eco and Deep Sleep modes.

App connectivity
Create your own designs with My Design Center and Artspira, create your own stitches with My Custom Stitch, get perfect placement with My Design Snap, keep an eye on your work whatever you’re doing with My Stitch Monitor and connect to your ScanNCut DX with My Connection.

LCD Display
Large and clear 10.1” (800 x 1280px) built-in HD LCD display.

Intuitive user interface
Easy-to-use screen layout and realistic preview of selected stitches and patterns.

USB connectivity
Two high-speed ports, can connect by mouse as well as optional external USB embroidery card reader.

Multilingual operational languages
12 built-in languages.

Safety features
Easily disengage needle to make changing presser feet and needles safer, and lock the screen to avoid any accidental stitch changes.

Updates
Automatic software update capability.

Embroidery Features

Embroidery area
Large 14 x 9.5” / 360 x 240mm embroidery area.

Embroidery speed
Embroidery up to 1,050 stitches per minute.

Built-in designs
Total 889 embroidery patterns including 101 Disney, monogram, and buttonhole shapes.

Built-in fonts
Built-in 26 embroidery fonts (24 alphabet and 2 Cyrillic). Two fonts include the full Eastern European font set.

Text edit functions
Simplified user interface for text input and editing, with various editing capabilities such as curving, arraying and space adjustment.

Font sizes
S/M/L size for font designs.

Built-in frame designs
140 frame pattern combinations.

Thread trimming
Jump stitch thread trimming with thread wiper.

Density
On-screen auto density adjustment (Stitch-To-Block) available for embroidery and letters.

LED pointer
Laser pointer for precise pattern placement.

Advanced editing functions
Design editing, flip designs horizontally, pattern rotating (0.1, 10 and 90 degrees), drag and drop operation, zoom up to 800% in My Design Centre and 200% otherwise.

Basting
Embroidery basting.

Colour Shuffling
Colour shuffling function that can choose from your favourite thread brands with more colour variations, with pinning, and favourite mark capability.

Stippling
No-fuss stippling in embroidery edit.

Selecting designs
Advanced multiple design selection.

Colour change
Direct touch button for changing colours of embroidery patterns.

Resume function
Resume your embroidery at the exact spot where you stopped in case of a power failure or accidental interruption.

Appliqué creator
Built-in Appliqué Creator; create multiple appliqués in one hoop with automatic best-placement repetition.

Optimised colour sorting
Quickly sort colours in different designs for optimised sewing order and to minimise thread changes.

Frame detection
Automatic embroidery frame size detection.

Progress bar
View the progress of an embroidery pattern or individual colour, and use to move forwards/backwards through the design.

Thread palettes
Select various thread brands for built-in and external designs and save up to nine of your favourite combinations.

Embroidery foot “W+” with LED pointer (on machine)

Needle set
- 75/11 6 needles: Ball point needle for embroidery

Bobbin × 10 (one bobbin is in machine)

Seam ripper

Scissors

Cleaning brush

Screwdriver (small)

Screwdriver (large)

Disc-shaped screwdriver

Spool cap (small)

Spool cap (medium) × 2 (one spool cap is on machine)

Spool cap (large)

Thread spool insert (mini king thread spool)

Spool felt (on machine)

Spool net × 2

Embroidery needle plate cover

Touch pen (stylus)

Bobbin case (no colour on the screw)

Embroidery frame
- 36 cm (H) × 24 cm (W) (approx. 14 inches (H) × 9 1/2 inches (W))

Embroidery frame
- 18 cm (H) × 13 cm (W) (approx. 7 inches (H) × 5 inches (W))

Lens calibration sheet

Embroidery bobbin thread (#90, white)

Accessory bag

Embroidery couching foot “Y”

Operation Manual

Embroidery Design Guide

1, Warranty registration.

There is no need to register your warranty. Please keep your receipt as proof of purchase. The product warranty is non-transferable should the machine be sold or given away at a later date.

2, To which products does this warranty cover.

This warranty applies to the machine and accessories (jointly referred to in this document as "this product"), with the exception of.

Needles, light bulbs, presser feet, bobbins, blades, tools and embroidery frames.

Other parts that need to be regularly maintained, filled or replaced and that are subject to normal wear and tear (including, but not limited to, bobbin cases, needle plates, belts and needle threaders and brackets).

Consumable items.

3, What does Brother warrant.

Brother warrants that the machine will be free from defects in material and workmanship, save for the exceptions set out in this document. The warranty covers the repair or replacement of the machine at Brother's expense and discretion, however no consequential damages that occur outside of this product, such as materials that have become unusable or loss of profit.

4, When does the warranty not apply to.

Material damage caused by external influences on this product

Damage caused by incorrect installation, incorrect or inappropriate use, misuse, negligence or accident (including, but not limited to, the transport of this product without proper preparation or packaging); and

Damage caused by other non-Brother devices or programmes used together with this product (including, but not limited to, the use of consumable items and accessory items).

This warranty shall become INVALID if this product is altered in any way (including, but not limited to, as a result of attempted warranty repairs without Brother's authorisation or alteration or removal of the serial number).

5, How long is the warranty valid.

This warranty shall be valid for 3 Years from the date of purchase.
If the machine is used for commercial use, the Warranty shall be valid for only 1 Year from the date of purchase.

6, Warranty repair.

If this machine develops a fault during the warranty period, Contact us on 01568 610044 or Email; refreshsewing@gmail.com Simply explain the fault and we shall help to rectify the fault in every way possible. Return the machine if needed so our tech department can check the machine. The original proof of purchase will be required as this will be needed to access the Brother warranty repair system.

Free delivery to England & Wales is available on this machine, Please allow 2-4 working days from time of purchase.

Collection available from our Leominster store.
