Brother Innov-is Stellaire XE2 Embroidery Machine.

 The Stellaire Innov-is XE2 embroidery machine is bursting with our latest technological innovations. With 889 embroidery patterns, two-point positioning, matrix copy, presser foot auto down, new in-the-hoop patterns, decorative, echo and stippling function, No Sew setting and so much more.

With an extra-large 10.1” HD touchscreen display, enhanced lighting, a working area of 360 x 240mm (14 x 9.5”), and speeds of up to 1,050 stitches per minute, it’s never been so easy to express yourself.

With 889 designs built-in as standard, including 101 Disney favourites, 26 lettering styles, 17 embroidered buttonholes and over 80 brand new motifs you’ve got more choices for more makes. Whether it’s one big motif, or smaller repeated designs, you won’t need to re-hoop with the Stellaire’s large 360 x 240mm (14 x 9.5”) frame and matrix copy function.

Take your bespoke ideas even further with easy-to-use text editing, colour shuffling, and enhanced thread palettes. There are nine built-in colour memory slots and expanded brand and colour choices.

We know how important being able to express your creativity is, and that’s why every Stellaire comes pre-loaded with Brother’s exclusive My Design Center software. This powerful, easy-to-use editing programme means that creating your own custom works of art has never been so easy, or so fun. Draw or doodle directly on the large touchscreen LCD display, with up to 800% zoom for pin-perfect accuracy.

Work smarter, not harder. The wireless enabled Stellaire Innov-is XE2 works in perfect harmony with a range of Brother apps, including Artspis, My Design Snap and My Stitch Monitor.

Key Features

Extra-large embroidery area: 360 x 240mm (14 x 9.5”)

889 built-in embroidery designs, including 101 Disney patterns

26 embroidery fonts (24 alphabets and 2 Cyrillic)

Monogram alphabet patterns, including candle wicking design

17 embroidered buttonholes

Advanced colour shuffling – save up to nine of your favourite palettes

Up to 1050spm embroidery speed

10.1” high resolution HD LCD screen

Wireless capability to work with Brother apps, Artspira, and PE-Design 11

Stitch to Block function – change size of embroidery keeping the stitch density

LED pointer embroidery foot

Matrix setting – automatically place repeated designs for the perfect layout

Auto jump stitch trimmer

USB port – making it easy to import designs

Built-in movie tutorials and MP4 upload function

What's In The Box

Embroidery foot “W+” with LED pointer (on machine)

Needle set
- 75/11 6 needles: Ball point needle for embroidery

Bobbin × 10 (one bobbin is in machine)

Seam ripper

Scissors

Cleaning brush

Screwdriver (small)

Screwdriver (large)

Disc-shaped screwdriver

Spool cap (small)

Spool cap (medium) × 2 (one spool cap is on machine)

Spool cap (large)

Thread spool insert (mini king thread spool)

Vertical spool pin

Bobbin clip × 10

Spool felt (on machine)

Spool net × 2

Embroidery needle plate cover

Touch pen (stylus)

Bobbin case (no color on the screw)

Bobbin cover (on machine)

Embroidery frame with decal set
- 36 cm (H) × 24 cm (W) (approx. 14 inches (H) × 9 1/2 inches (W))

Embroidery frame with decal set
- 18 cm (H) × 13 cm (W) (approx. 7 inches (H) × 5 inches (W))

Embroidery positioning sticker sheets × 4

Lens calibration sheet

Embroidery bobbin thread (#90, white)

Stabilizer material

Accessory bag

Embroidery couching foot “Y”

Yarn guide for embroidery couching

Yarn threader

Operation Manual

Embroidery Design Guide

General Features

Lighting
Almost 11” of full-spectrum lighting around the needle with five adjustable brightness settings including off.

Needle threader
Easy to use, automatic needle threading system.

Bobbin winder
Independent bobbin winder system with adjustable winding speed.

Wireless
Wireless LAN capability for exchange of embroidery data with PE-Design 11, mobile apps and updates.

Thread tension
Automatic thread tension.

Thread cutter
Trims upper and lower threads automatically.

Presser foot
Automatic presser foot lift and extra high lift.

Thread sensors
Gives you a warning when your upper and lower threads are running low.

Teaching movies
Wide selection of built-in tutorial videos and MP4 playability.

Start/stop button
Ergonomic large start/stop button.

Environment
Save energy with the Eco and Deep Sleep modes.

App connectivity
Create your own designs with My Design Center and Artspira, create your own stitches with My Custom Stitch, get perfect placement with My Design Snap, keep an eye on your work whatever you’re doing with My Stitch Monitor and connect to your ScanNCut DX with My Connection.

LCD Display
Large and clear 10.1” (800 x 1280px) built-in HD LCD display.

Intuitive user interface
Easy-to-use screen layout and realistic preview of selected stitches and patterns.

USB connectivity
Two high-speed ports, can connect by mouse as well as optional external USB embroidery card reader.

Multilingual operational languages
12 built-in languages.

Safety features
Easily disengage needle to make changing presser feet and needles safer, and lock the screen to avoid any accidental stitch changes.

Updates
Automatic software update capability.

Embroidery Features

Embroidery area
Large 14 x 9.5” / 360 x 240mm embroidery area.

Embroidery speed
Embroidery up to 1,050 stitches per minute.

Built-in designs
Total 889 embroidery patterns including 101 Disney, monogram, and buttonhole shapes.

Built-in fonts
Built-in 26 embroidery fonts (24 alphabet and 2 Cyrillic). Two fonts include the full Eastern European font set.

Text edit functions
Simplified user interface for text input and editing, with various editing capabilities such as curving, arraying and space adjustment.

Font sizes
S/M/L size for font designs.

Built-in frame designs
140 frame pattern combinations.

Thread trimming
Jump stitch thread trimming with thread wiper.

Density
On-screen auto density adjustment (Stitch-To-Block) available for embroidery and letters.

LED pointer
Laser pointer for precise pattern placement.

Advanced editing functions
Design editing, flip designs horizontally, pattern rotating (0.1, 10 and 90 degrees), drag and drop operation, zoom up to 800% in My Design Centre and 200% otherwise.

Basting
Embroidery basting.

Colour Shuffling
Colour shuffling function that can choose from your favourite thread brands with more colour variations, with pinning, and favourite mark capability.

Stippling
No-fuss stippling in embroidery edit.

Selecting designs
Advanced multiple design selection.

Colour change
Direct touch button for changing colours of embroidery patterns.

Resume function
Resume your embroidery at the exact spot where you stopped in case of a power failure or accidental interruption.

Appliqué creator
Built-in Appliqué Creator; create multiple appliqués in one hoop with automatic best-placement repetition.

Optimised colour sorting
Quickly sort colours in different designs for optimised sewing order and to minimise thread changes.

Frame detection
Automatic embroidery frame size detection.

Progress bar
View the progress of an embroidery pattern or individual colour, and use to move forwards/backwards through the design.

Thread palettes
Select various thread brands for built-in and external designs and save up to nine of your favourite combinations.

Included frames
Two standard frames, compatible with My Design Snap, included – 360 x 240mm (14 x 9.5”) and 180 x 130mm (7 x 5”).

5 Year Warranty
